La machine adaptée à votre chantier

De 1.0 à 10 tonnes, les mini-pelles Ammann se distinguent par leur polyvalence et leur haut degré de personnalisation. Une gamme de machines compactes et puissantes, conçues pour garantir d’excellentes performances sur tous les chantiers.

Dimensions compactes

Compactes mais toujours puissantes. Telles sont les caractéristiques des mini-pelles Ammann AMX. Elles offrent une productivité extraordinaire tout en s’adaptant aux situations les plus difficiles et aux chantiers les plus étroits, à l’intérieur comme à l’extérieur.

Travailler confortablement

Les mini-pelles Ammann permettent un travail productif avec une souplesse maximale. Dans le but de proposer précision et sécurité, Ammann a développé la gamme AMX en privilégiant la visibilité pour l’opérateur. La position et la conception de la cabine ont été conçues pour offrir une visibilité totale de l’environnement autour de la machine et de sa zone de travail.

Utilisation simplifiée

La disposition intuitive de toutes les commandes facilite le travail et l’opérateur peut se concentrer à 100 % sur son travail.



Units:

AMX 12

MINI PELLES
Poids opérationnel
1185 kg
Largueur maximale
790–1050 mm
Profondeur d’excavation max.
1860–1980 mm
Moteur
Kubota D722 Stage V
Puissance
10.2 kW | 13.7 cv

AMX 14

MINI PELLES
Poids opérationnel
1255 kg
Largueur maximale
790–1050 mm
Profondeur d’excavation max.
2045–2175 mm
Moteur
Kubota D722 Stage V
Puissance
10.2 kW | 13.7 cv

𝘦AMX 15

MINI PELLES
Poids opérationnel
1340 kg
Largueur maximale
790–1050 mm
Profondeur d’excavation max.
2045–2175 mm
Moteur
Aimants Permanents Interieurs (IPM)
Puissance
21.5 kWh

AMX 16

MINI PELLES
Poids opérationnel
1710–1790 kg
Largueur maximale
990–1250 mm
Profondeur d’excavation max.
2020 mm
Moteur
Yanmar 3TNV70 Stage V
Puissance
11.2 kW | 15.2 cv

AMX 18-2

MINI PELLES
Poids opérationnel
1860–1940 kg
Largueur maximale
990–1300 mm
Profondeur d’excavation max.
2280–2480 mm
Moteur
Yanmar 3TNV70 Stage V
Puissance
11.2 kW | 15.2 cv

AMX 19

MINI PELLES
Poids opérationnel
1900–1980 kg
Largueur maximale
990–1300 mm
Profondeur d’excavation max.
2280–2480 mm
Moteur
Yanmar 3TNV76 Stage V
Puissance
13.7 kW | 18.6 cv

AMX 24-2

MINI PELLES
Poids opérationnel
2090–2190 kg
Largueur maximale
990–1300 mm
Profondeur d’excavation max.
2560–2760 mm
Moteur
Kubota D1105 Stage V
Puissance
15.4 kW | 20.9 cv

AMX 25

MINI PELLES
Poids opérationnel
2410–2540 kg
Largueur maximale
1500 mm
Profondeur d’excavation max.
2725–2925 mm
Moteur
Yanmar 3TNV76 Stage V
Puissance
15.5 kW | 21.1 cv

AMX 28

MINI PELLES
Poids opérationnel
2700–2850 kg
Largueur maximale
1550 mm
Profondeur d’excavation max.
2660–2860 mm
Moteur
Kubota D1703-M-DI Stage V
Puissance
18.5 kW | 25 cv

AMX 35

MINI PELLES
Poids opérationnel
3350–3500 kg
Largueur maximale
1580 mm
Profondeur d’excavation max.
2880–3080 mm
Moteur
Kubota D1703-M-DI Stage V
Puissance
18.5 kW | 25 cv

AMX 42

MINI PELLES
Poids opérationnel
4050–4200 kg
Largueur maximale
1750 mm
Profondeur d’excavation max.
3085–3335 mm
Moteur
Kubota D1803-CT R Stage V
Puissance
32.3 kW | 43.9 cv

AMX 45

MINI PELLES
Poids opérationnel
4450–4600 kg
Largueur maximale
1750 mm
Profondeur d’excavation max.
3230–3480 mm
Moteur
Kubota D1803-CT R Stage V
Puissance
32.3 kW | 43.9 cv

AMX 50

MINI PELLES
Poids opérationnel
4800 kg
Largueur maximale
1900 mm
Profondeur d’excavation max.
3330–3580 mm
Moteur
Kubota V22403 CR T Stage V
Puissance
42.6 kW | 57.9 cv

AMX 55

MINI PELLES
Poids opérationnel
5250 kg
Largueur maximale
1900 mm
Profondeur d’excavation max.
3490–3740 mm
Moteur
Kubota V22403 CR T Stage V
Puissance
42.6 kW | 57.9 cv

AMX 60

MINI PELLES
Poids opérationnel
5700 kg
Largueur maximale
1980 mm
Profondeur d’excavation max.
3850–4100 mm
Moteur
Kubota V2607 CR T Stage V
Puissance
45.0 kW | 61.2 cv

AMX 65

MINI PELLES
Poids opérationnel
6200 kg
Largueur maximale
1980 mm
Profondeur d’excavation max.
3950–4200 mm
Moteur
Kubota V2607 CR T Stage V
Puissance
45.0 kW | 61.2 cv

AMX 75

MINI PELLES
Poids opérationnel
7290 kg
Largueur maximale
2100 mm
Profondeur d’excavation max.
4070 (4270) mm
Moteur
Kubota V2607 CR T Stage V
Puissance
44.3 kW | 60.2 cv

AMX 80

MINI PELLES
Poids opérationnel
7580 kg
Largueur maximale
2100 mm
Profondeur d’excavation max.
4120 (4320) mm
Moteur
Kubota V2607 CR T Stage V
Puissance
44.3 kW | 60.2 cv

AMX 85

MINI PELLES
Poids opérationnel
9320 kg
Largueur maximale
2320 mm
Profondeur d’excavation max.
4270–4620 mm
Moteur
Yanmar 4TNV98 Stage V
Puissance
53.7 kW | 73.0 cv

AMX 95 DDP

MINI PELLES
Poids opérationnel
9100 kg
Largueur maximale
2320 mm
Profondeur d’excavation max.
4220–4570 mm
Moteur
Yanmar 4TNV98CT Stage V
Puissance
53.7 kW | 73.0 cv

AMX 95 MONO

MINI PELLES
Poids opérationnel
9100 kg
Largueur maximale
2320 mm
Profondeur d’excavation max.
3800–4150 mm
Moteur
Yanmar 4TNV98CT Stage V
Puissance
53.7 kW | 73.0 cv

AMX 100

MINI PELLES
Poids opérationnel
9900 kg
Largueur maximale
2320 mm
Profondeur d’excavation max.
4570–4920 mm
Moteur
Yanmar 4TNV98CT Stage V
Puissance
53.7 kW | 73.0 cv

Ce qui distingue les mini pelles AMX Ammann

OUVRIR TOUT

Compacite

Des dimensions extrêmement compactes permettent aux mini pelles de la gamme AMX Ammann de se faufiler dans les lieux étroits et d’évoluer dans des espaces restreints auxquels d’autres machines ne peuvent pas accéder.

Concept ZT

La conception ZT (ZT = Zero Tail) permet à la majorité des modèles de ne pas que leur gabarit ne dépassent pas de l’encombrement de leurs chenilles, pour des chantiers sûrs, en toutes circonstances.

Parfait équilibre

Le rapport poids / puissance / performance des mini pelles AMX Ammann leur procure stabilité, productivité et sécurité.

Facilité d’entretien

La majeure partie de la gamme AMX propose un concept global facilitant la maintenance quotidienne de la machine : plateforme de l’opérateur basculante (AMX 24-2 à AMX 65) et larges capots ouvrants pour l’accès aux points de maintenance.

Plateforme spacieuse

Sur l’ensemble des modèles, l’espace reservé à l’opérateur est spacieux, bien isolé et conçu de façon ergonomique afin de garantir un confort optimal, même pendant de longues journées de travail.
